Brea Tech Micro Motor
1 / 5
| Gearbox with motor Data: GM1812-N20-11135-3.0V | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Reduction Ratio | 42 | 80 | 105 | 121 | 158 | 230 | 302 | 346 | 453 |
| Length (mm) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| No-load speed (rpm) | 267 | 140 | 107 | 93 | 71 | 49 | 37 | 32 | 25 |
| Rated speed (rpm) | 229 | 120 | 91 | 79 | 61 | 42 | 32 | 28 | 21 |
| Rated torque (kg.cm) | 0.05 | 0.10 | 0.13 | 0.15 | 0.19 | 0.23 | 0.30 | 0.35 | 0.45 |
| Stalling Torque (kg.cm) | 0.35 | 0.67 | 0.88 | 1.02 | 1.33 | 1.61 | 2.11 | 2.42 | 3.17 |
| Gearbox with motor Data: GM1812-N20-05600-12.0V | |||||||||
| Reduction Ratio | 105 | 121 | 158 | 230 | 302 | 346 | 453 | 692 | 906 |
| Length (mm) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| No-load speed (rpm) | 219 | 190 | 146 | 100 | 76 | 66 | 51 | 33 | 25 |
| Rated speed (rpm) | 198 | 172 | 132 | 90 | 69 | 60 | 46 | 30 | 23 |
| Rated torque (kg.cm) | 0.13 | 0.15 | 0.19 | 0.23 | 0.30 | 0.35 | 0.45 | 0.69 | 0.91 |
| Stalling Torque (kg.cm) | 1.32 | 1.52 | 1.98 | 2.40 | 3.16 | 3.62 | 4.74 | 7.23 | 9.47 |
We are a high-tech enterprise that integrates the research and development, production, and marketing of micro motor series products. The main products include: various precision DC motors, stepper motors, reduction motors, planetary reduction motors, and brushless motors.
Micro motors are widely used in medical equipment, medical detection and analysis, financial security, 5G applications, automotive appliances, intelligent communication, iris technology, AI intelligence, smart grid, smart home, commercial intelligent locks, smart switches, smart medicine cabinets, fresh food cabinets, smart wear, outdoor equipment, intelligent robots, electric tools, beauty tools, and more.
Since our establishment, we have adhered to the concept of "people-oriented, pioneering and innovative spirit". With a young, pragmatic, professional, and efficient work team, advanced production facilities, efficient management, excellent quality, and high-quality services, we consistently meet customer needs for improving product levels, reducing energy consumption, facilitating production, and improving operational efficiency.
